PXI-6528
$1,200.00
Item details
Bus Connector: PXI Hybrid
Single-Ended Digital I/O Channel Current Drive: 150 mA
Digital I/O Logic Levels: 60 V
Number of Digital Input Only Channels: 24
Number of Digital Output Only Channels: 24
Number of Bidirectional Digital Channels: –
Digital Input Voltage Range: -60 V to 60 V
Output Voltage Range: -60 V to 60 V
Maximum Clock Rate: –
Signaling Type: Single-Ended
12
People watching this product now!
-
Warranty 1 year
-
Free 30-Day returns
付款方式：
NI PXI-6528 Digital I/O Module Description
48-Channel, 24 Sink/Source Inputs, 24 Sink/Source Outputs, Channel-Channel Isolated, PXI Digital I/O Module
The PXI‑6528 is an industrial, parallel digital I/O interface. With programmable power-up states, you can configure the initial output states in software to ensure safe operation when connected to industrial actuators. If a computer or application fault occurs, the PXI‑6528 can use digital I/O watchdogs to switch to a configurable safe output state to ensure detection and safe recovery from fault conditions. Programmable input filters eliminate glitches/spikes and provide debouncing for digital switches/relays through a software-selectable digital filter.
Part Number(s): 778543-01
Specification
Overview
| Brand |
National Instruments |
|---|
